I'm having some trouble with the preamp section of my Toshiba RT-9000S. It's proving quite tricky to trace a signal through from the phono inputs to the power amp IC input, and to make life easier I'd like to get my hands on a schematic and PCB layout for this boombox.
I've so far failed to find any documentation online, and a hopeful purchase of a manual from Analog Alley for an RT-8700S (a boombox that's outwardly very similar to my 9000S) hasn't proved all that helpful - it turns out that there's quite a lot of difference between the PCBs of the two machines.
Has anyone ever come across any schematics etc specific to the RT-9000S?
I've so far failed to find any documentation online, and a hopeful purchase of a manual from Analog Alley for an RT-8700S (a boombox that's outwardly very similar to my 9000S) hasn't proved all that helpful - it turns out that there's quite a lot of difference between the PCBs of the two machines.
Has anyone ever come across any schematics etc specific to the RT-9000S?
