AKAI AJ-500 belts sizes

[Funkateer38]

Hello,

I am looking for AKAI AJ-500' s belts sizes same as AKAI AJ-490.
Thank you in advance
Best regards



[hopey]

Found these for 520 maybe the same

AJ-520FS/FL


1-23 MB703339 Driver Belt 2575533500
1-85 MB703362 Belt 1K41 2575535900
1-119 MB703379 Belt 1K46.5 2575539000



[Funkateer38]

Thank you Hopey for your attention and clarifications.
But what are the dimensions (inner circumference, width and thickness) or the PRB references



[caution]

The 490, 500, 520 and 530 all use the same two belt types, so Akai belt sets for any of these models will work.
Icedmelon702 sold these 3-belt sets as recently as July (here) so you might want to contact him to see if he has more.

These do not have a PRB code, old or new format, so if nobody here responds, and you're determined to find the belt specs to avoid waiting for an ebay seller, you'll have to measure the cross section of your old belts. Snugly wrap some thread or wire around the belt paths and subtract 5% to find the ideal length. I can help convert your measurements into a belt code.

Some sites do let you look up belts by vendor part number, but I didn't see MB703339 or MB703379.
Not sure where Hopey got that drive belt number, but it's not what the service manuals list.

The AJ-500FS/FL service manual
MB703339 Drive Belt AJ-490 2575533500
(2x) MB703379 Belt 1K46.5 AJ-490 2575539000

AJ-520/530 FS/FL service manual
MB703339 Drive Belt 2575533500
(2x) MB703379 Belt 1K46.5 2575539000



[caution]

Nevermind, totally missed the counter belt



[hopey]

The 490, 500, 520 and 530 all use the same two belt types, so Akai belt sets for any of these models will work.
Icedmelon702 sold these 3-belt sets as recently as July (here) so you might want to contact him to see if he has more.

These do not have a PRB code, old or new format, so if nobody here responds, and you're determined to find the belt specs to avoid waiting for an ebay seller, you'll have to measure the cross section of your old belts. Snugly wrap some thread or wire around the belt paths and subtract 5% to find the ideal length. I can help convert your measurements into a belt code.

Some sites do let you look up belts by vendor part number, but I didn't see MB703339 or MB703379.
Not sure where Hopey got that drive belt number, but it's not what the service manuals list.

The AJ-500FS/FL service manual
MB703339 Drive Belt AJ-490 2575533500
(2x) MB703379 Belt 1K46.5 AJ-490 2575539000

AJ-520/530 FS/FL service manual
MB703339 Drive Belt 2575533500
(2x) MB703379 Belt 1K46.5 2575539000

I found the service manual for 520 I think they are the same as well as the tape counter belt.
